Ledvance LED floodlight FLOODLIGHT MAX POWER SUPPLY 1200W WAL - 4058075580749
LEDVANCE
Ledvance LED floodlight FLOODLIGHT MAX POWER SUPPLY 1200W WAL - 4058075580749
Product number:
4058075580749
Content:
1 Stück
Shipping in 3 day(s)
€1,604.89
Content:
1 Stück
net €1,348.65
Product information "Ledvance LED floodlight FLOODLIGHT MAX POWER SUPPLY 1200W WAL - 4058075580749"
Power supplies for Floodlight Max. Product properties: Electricity supply for Floodlight Max lighting heads. Joint or separate installation with Floodlight Max Leuchtenkopf. M20 and M25 PG screw connections for the power cable introduction. Connection of the LED modules using a pre-installed connector with quick lock. High overvoltage protection of up to 10 kV (L/N-PE and L-N). Product advantages: extremely robust and durable. Faster and simple network connection, thanks to tool -free housing opening. Optimized product logistics, lighting heads and power supplies are packed separately. 5 years of guarantee. Areas of application: external application (IP66). Large area lighting. Sports facilities. Construction sites. Technical equipment: Extension cable and mast assembly set for power supply in preparation
Electrical data
| operating frequency: | 50 Hz |
|---|---|
| rated voltage: | 220-240 V |
| system power: | 1200 |
| switching cycles: | 100000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | rectangular |
| protection type: | IP66 |
| impact resist: | IK08 |
| protection class: | I |
| environment temperature from: | -30 °C |
| environment temperature to: | 50 °C |
Photometric data
| dimmable: | no |
|---|---|
| color: | grey |
| solar panel: | no |
| start time: | 0,5 s |
Logistic data
| item category: | luminaire accessories |
|---|---|
| country of origin: | China |
Dimensions & packaging
| EAN | 4058075580749 |
|---|---|
| Length | 270 mm |
| Width | 447 mm |
| Height | 166 mm |
| Weight | 12600 g |
