Tridonic LED-driver LC 17W 250-400mA flexC SR SNC4 - 87501087
Tridonic GmbH & Co KG
Tridonic LED-driver LC 17W 250-400mA flexC SR SNC4 - 87501087
Product number:
87501087
Immediately available
€7.85
net €6.60
Product information "Tridonic LED-driver LC 17W 250-400mA flexC SR SNC4 - 87501087"
- Independent fixed output LED driver
- For luminaires of protection class II
- For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
- Temperature protection as per EN 61347-2-13 C5e
- Selectable fixed output current via DIP switch 250, 300, 350 and 400 mA (pre-selected current 250 mA)
- Max. output power 16.8 W
- Up to 85.5 % efficiency
- Nominal lifetime up to 100,000 h
Housing properties Casing:
- polycarbonate, white
- Type of protection IP20
Interfaces
- Terminal blocks: 45° push terminals
Functions
- Overload protection
- Short-circuit protection
- No-load protection
- Overtemperature protection
- Burst protection voltage 1 kV Burst protection voltage 1 kV (L to N)
- Surge protection voltage 2 kV (L/N to earth)
Typical applications
- For spot light and downlight in retail and hospitality applications
- For panel light and area light in office and education application
Downloads & Documents
