Lunatone control module DALI DALI-2 MC4L DIN Rail instances activated – 86458507-4L-HS-2-INT
Lunatone control module DALI DALI-2 MC4L DIN Rail instances activated – 86458507-4L-HS-2-INT
Immediately available
€101.46
net €85.26
Product information "Lunatone control module DALI DALI-2 MC4L DIN Rail instances activated – 86458507-4L-HS-2-INT"
DALI-2 MC4L DIN Rail_ factory setting: Instances activated
DALI-2 MC4L DIN Rail
Interface with 4, from the DALI bus galvanically isolated, inputs for mains voltage. Each input can be individually configured with target address, button behaviour and DALI commands. Besides the standard functions, dimming, switching, scene recall, etc., predefined macros such as setting the colour temperature, dynamic scenes and sequences as well as user defined command lists are supported. Suitable for DIN rail mounting.
With variant 86458507-4L-HS-2-app, the application controller is activated. In addition to the standard DALI commands, the DALI DT8 TC and RGB (W) control is also supported. The device can also be set to instance mode with the DALI Cockpit PC Software.
The variant 86458507-4L-HS-2-int is set to instance mode (no direct DALI control commands) for integration into higher-level building management systems from e.g. WAGO, Beckhoff. The application controller can be activated with the DALI Cockpit PC Software.
Electrical data
| conformity: | CE |
|---|
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | round |
| protection type: | IP21 |
| material: | plastic |
| mounting: | Installation |
| protection class: | II |
| environment temperature from: | -20 °C |
| environment temperature to: | 60 °C |
Photometric data
| color: | white |
|---|---|
| interface: | DALI-2 |
| sensor type: | passive infrared |
| solar panel: | no |
Dimensions & packaging
| EAN | 9010342016103 |
|---|---|
| Length | 59 mm |
| Width | 33 mm |
| Height | 15 mm |
| Weight | 56 g |
Lunatone Industrielle Elektronik GmbH
Paukerwerkstraße 5
1210 Wien
AT
office@lunatone.com
www.lunatone.com
