PEHA Light Management PIR-motion detector with photocell LightSpot BattenFit - 990303
PEHA Light Management PIR-motion detector with photocell LightSpot BattenFit - 990303
Immediately available (4 articles directly deliverable)
That's why you should buy this product now
- Excellent reviews on Trustpilot
- 4.8 out of 5 ⭐⭐⭐⭐⭐ on Google
- Short delivery times for stock items
- Very good price-performance ratio
- Highest possible quality standards
- Products from renowned manufacturers
€67.18
Prices incl. VAT plus shipping costs net €56.45
Product information "PEHA Light Management PIR-motion detector with photocell LightSpot BattenFit - 990303"
With the aid of PEHA LightSpot series recessed mounted PIR motion detector with integrated passive / active photocell, you can control your lighting energy efficiently. The presence detector is suitable for max. 4 DALI ballasts and has a switching output for light strips.
When no one is in the room, the lights are turned off, and they are dimmed or turned off when there is enough daylight - the savings are automatic and can be as much as 80% per annum. In addition, the maintenance costs are reduced. The lamps are brighter, last longer and do not need to be replaced frequently.
The motion detector has a 360 ° detection range (corresponds approximately to a diameter of 5.6m or 11.2m at a mounting height of 2.5m or 5m.). The follow-up time is between 10 seconds to 96 hours. Since all parameters are preconfigured, the motion detector can be easily put into operation.
In addition, the PEHA LightSpot presence detector can be used in a high mounting height and is in compliance with the applicable building regulations. The housing has IP65 protection.
The PIR motion detector can be operated manually with IR remote control D HC5A. The parameterization can be done via the manual programmer D HP18 or the programming software QUICKSETPRO.
Downloads & Documents
Login
Electrical data
| rated voltage: | 230 V |
|---|
Casing
| form type: | linear |
|---|---|
| protection type: | IP65 |
| mounting: | Installation |
Photometric data
| sensor: | yes |
|---|---|
| detection angle: | 360 ° |
| color: | white |
| sensor type: | passive infrared |
Logistic data
| item category: | sensors |
|---|
Dimensions & packaging
| Length | 135 mm |
|---|---|
| Width | 40 mm |
| Height | 29 mm |
| Weight | 170 g |
