Product description

• Dimmable 24 V constant voltage LED driver for flexible constant voltage LED strips
• one4all interface enables different dimming options
• Dimming range from 1 to 100 %
• No additional external dimmer required
• lumDATA (DALI-2 parts 251, 252 and 253)
• Can be used as a built-in or independent LED driver with clip-on strain relief (see data sheet, chapter "1. Standards")
• The strain relief is included in both packaging variants. In the single packaging (SP), each driver is additionally individually packaged.
• Suitable for emergency escape lighting systems according to EN 50172
• Nominal lifetime up to 50,000 h

Functions

• LTI (Lifetime Indicator)

Typical applications

• Ambient and decorative lighting
• Cove lighting
• Façade accent lighting

Technical details

• 24 V, 60 W
• Compact design
• Push terminals for easy wiring
• Dual output terminals (+/–) for greater flexibility in applications

Interfaces

• Near-field communication (NFC)
• one4all (DALI-2, DSI, switchDIM, corridorFUNCTION)
• Terminal blocks: 45° push terminals

System solution

• Tridonic LLE FLEX 24V SNC4
• Tridonic LLE FLEX 24V EXC4
• For use with ACL FLEX accessory cable to PCB
• When using light sources from other manufacturers, test their dimming performance at low dimming levels beforehand to ensure proper operation.
