Tridonic GmbH & Co KG
Tridonic ECG-LED TRIDONIC LCBI 10W 350mA phase-cut/1-10V lp - 87500283
Product number:
87500283
Tridonic GmbH & Co KG
Tridonic ECG-LED TRIDONIC LCBI 10W 350mA phase-cut/1-10V lp - 87500283
Product number:
87500283
Shipping in 21 day(s)
That's why you should buy this product now
- High Quality at a low price
- 4.8 out of 5 ⭐⭐⭐⭐⭐ on Google
- Short delivery times for stock items
€15.93
Content:
1 Stück
Prices incl. VAT plus shipping costs net €13.39
Product information "Tridonic ECG-LED TRIDONIC LCBI 10W 350mA phase-cut/1-10V lp - 87500283"
For luminaires of protection class I and protection class II
Push-in terminals
Short-circuit protection
SELV
Constant current LED Driver
Type of protection IP20
Overload protection
No-load protection
5-year guarantee
Casing: polycarbonate, white
Output dimmed analogue (current amplitude)
Output power 10 W
Temperature protection as per EN 61347-2-13 C5e
Dimmable via leading edge and trailing edge phase dimmers
Dimmable via 1 ... 10 V
Dimming range typ. 10 to 100 % (depending on dimmer)
Nominal life-time up to 50,000 h
No output current overshoot at mains on/off
Output current 180, 350 or 500 mA
Dimmable built-in constant current LED Driver
Push-in terminals
Short-circuit protection
SELV
Constant current LED Driver
Type of protection IP20
Overload protection
No-load protection
5-year guarantee
Casing: polycarbonate, white
Output dimmed analogue (current amplitude)
Output power 10 W
Temperature protection as per EN 61347-2-13 C5e
Dimmable via leading edge and trailing edge phase dimmers
Dimmable via 1 ... 10 V
Dimming range typ. 10 to 100 % (depending on dimmer)
Nominal life-time up to 50,000 h
No output current overshoot at mains on/off
Output current 180, 350 or 500 mA
Dimmable built-in constant current LED Driver
Downloads & Documents
Login
Electrical data
| output current: | 350 |
|---|---|
| operating mode: | constant current |
| rated voltage: | 220-240 V |
| lifetime: | 50000 h |
Casing
| form type: | linear |
|---|---|
| max housing temperature (tc-max): | 65 °C |
| protection type: | IP20 |
| environment temperature from: | -20 °C |
| environment temperature to: | 50 °C |
Photometric data
| color: | white |
|---|---|
| interface: | phase cut and gating |
Logistic data
| item category: | LED drivers |
|---|
Dimensions & packaging
| EAN | 9006210511337 |
|---|---|
| Length | 139 mm |
| Width | 30 mm |
| Height | 21 mm |
| Weight | 62 g |
