Philips / Signify RC132V G4 LED34S/830 PSD W60L60 OC - 36046100
Philips / Signify RC132V G4 LED34S/830 PSD W60L60 OC - 36046100
Immediately available
€76.06
net €63.92
Product information "Philips / Signify RC132V G4 LED34S/830 PSD W60L60 OC - 36046100"
830 Warm white - Electronic control gear, DALI controllable
Delivers on the CoreLine promise - Innovative, easy to install andIn new and renovated buildings, luminous surfaces are often used to illuminate the whole area.panel luminaires are used, which provide high-quality lighting and aretheir high efficiency and long service life considerable energy and maintenance costssave. CoreLine Panel is available in two versions:a screen workstation-compatible (BAP-compatible) (OC) panel with integrated,wide beam micro-optics and an opals panel (NOC). The new CoreLine panelsLED inlay lights can also be used as a replacement forof conventional fluorescent lamps are used. They letcan be installed easily and quickly. The BAP-suitable luminaires are additionallywith an optional suspension set to convert it to a direct radiating pendant luminaire.
Downloads & Documents
Electrical data
| rated voltage: | 220-240 V |
|---|---|
| lifetime: | 50000 h |
Casing
| protection type: | IP20 |
|---|---|
| mounting: | surface mounting |
| impact resist: | IK03 |
| protection class: | II |
| environment temperature from: | 10 °C |
| environment temperature to: | 40 °C |
Photometric data
| sensor: | no |
|---|---|
| color code: | 830 |
| color: | white |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >80 |
| lamp efficiency: | 117 lm/W |
| lum flux: | 3400 lm |
Logistic data
| item category: | LED panel luminaires |
|---|
Dimensions & packaging
| EAN | 8710163360461 |
|---|---|
| Length | 595 mm |
| Width | 595 mm |
| Height | 11 mm |
| Weight | 2900 g |
