Osram LED-Driver OT FIT 75/220-240/500 D NFC F L - 4062172063968
Inventronics Europe BV
Osram LED-Driver OT FIT 75/220-240/500 D NFC F L - 4062172063968
Product number:
4062172063968
Content:
1 Stück
Immediately available
€24.32
Content:
1 Stück
net €20.44
Product information "Osram LED-Driver OT FIT 75/220-240/500 D NFC F L - 4062172063968"
Product family benefits
- Flat housing (16 mm height) for innovative luminaire designs and applications
- Flexible and future-proof current setting via NFC (Near Field Communication)
- Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
- Higher quality of light thanks to < 1% output ripple current
- Very high efficiency
- Fulfill safety requirement due to overload, overtemperature protection
Areas of application
- Linear and area lighting
- Industry lighting
- Suitable for luminaires of protection class I
Electrical data
| number of channels: | 1 |
|---|---|
| output current: | 125, 150, 175, 200, 225, 250, 275, 300, 325, 350, 375, 400, 425, 450, 475, 500 |
| operating mode: | constant current |
| rated voltage: | 220-240 V |
| conformity: | BIS, CCC, CE, EAC, ENEC, RCM |
| lifetime: | 100000 h |
Casing
| fire protection: | no |
|---|---|
| form type: | linear |
| max housing temperature (tc-max): | 75 °C |
| protection type: | IP20 |
| material: | metal |
| mounting: | universal mounting |
| protection class: | I/II |
| environment temperature from: | -20 °C |
| environment temperature to: | 50 °C |
Photometric data
| color: | white |
|---|---|
| lamp type: | LED |
Dimensions & packaging
| Length | 280 mm |
|---|---|
| Width | 30 mm |
| Height | 16 mm |
| Weight | 205 g |
