Product information "Lunatone Light Management Zentrales DALI-Control Module DALI 4Net - 22176666"
The central DALI control module DALI 4Net from Lunatone enables the independent light control of up to 256 DALI ballasts on 4 DALI lines. It can be configured via Ethernet using the PC software DALI Cockpit. In addition, Modbus TCP is used for control and visualization.
The interface is multimaster-capable: Several DALI control devices (input devices and sensors) can be used on each DALI line. In addition to the basic functions, the DALI 4Net has a crossline functions for input devices and a programmable schedule function / real time clock).
The Lunatone control module is supplied with 24V DC and is suitable for DIN rail mounting.
Downloads & Documents
Bedienungsanleitung-Lunatone-Lichtmanagement-Zentrales-DALI-Steuermodul-DALI-4Net-22176666_1592166665_5
Instruction-manual-Lunatone-Light-Management-Central-DALI-Control-module-DALI-4Net-22176666_1592166665_6
Datenblatt-Lunatone-Lichtmanagement-Zentrales-DALI-Steuermodul-DALI-4Net-22176666_1592166665_7
Login
Electrical data
| rated voltage: | 24 V |
|---|---|
| conformity: | CE |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| protection type: | IP20 |
| mounting: | rail |
| environment temperature from: | -10 °C |
| environment temperature to: | 50 °C |
Photometric data
| sensor: | no |
|---|---|
| color: | white |
| interface: | DALI |
| solar panel: | no |
Logistic data
| item category: | light management |
|---|
Dimensions & packaging
| EAN | 9010342010095 |
|---|---|
| Length | 98 mm |
| Width | 17 mm |
| Height | 56 mm |
| Weight | 66 g |
