Lunatone LED-Driver DALI-2 24V LED Power Supply CV DT6 - 89453849-350
Lunatone
Lunatone LED-Driver DALI-2 24V LED Power Supply CV DT6 - 89453849-350
Product number:
89453849-350
Immediately available
€69.37
net €58.29
Product information "Lunatone LED-Driver DALI-2 24V LED Power Supply CV DT6 - 89453849-350"
Product Information
- 1 channel LED Power Supply
- types for constant voltage (24V) and constant current (250mA, 350mA, 500mA, 700mA, 1050mA) available
- control via DALI-address (DT6)
- SwitchDim2: level control via switching inputs without DALI
- dimming range from 0.1%-100%
- pwm-frequency adjustable (122Hz/244Hz/488Hz/976Hz from FW version 5 on changed PWM frequencies: 122Hz / 250Hz / 500Hz / 1kHz)
- suitable for integration in luminaires and remote ceiling
- supply voltage 230V AC
- CV-type: output 24V PWM, 1A max.
- CC-type: output with 250mA, 350mA, 500mA, 700mA or 1050mA
- low standby power consumption
- high efficiency
- configuration with DALI-Cockpit software tool and DALI USB interface
- overtemperature shutdown, integrated short circuit protection
- user-friendly factory default settings
