Product benefits

• No bending thanks to glass technology
• Quick, simple and safe replacement without rewiring
• Energy savings of up to 60 % (compared to T8 fluorescent lamp)
• Very high resistance to switching loads
• High luminous flux for sophisticated lighting tasks
• Support the implementation of the HACCP concepts from production through to presentation
• Also suitable for operation at low temperatures

Areas of application

• General illumination within ambient temperatures from -20…+45 °C
• Illumination of production areas
• Traffic zones and corridors
• Supermarkets and department stores
• Industry

Product features

• LED replacement for classic T8 fluorescent lamps with G13 socket for use in CCG, ECG luminaires or on AC mains
• Compatible with conventional and many common electronic control gears and line voltage
• Low flicker according to EU 2019-2020 (SVM ≤ 0.4 / PstLM ≤ 1)
• Lamp tube made of glass with splinter protection
• For especially uniform illumination
• Type of protection: IP20
• Lifetime up to 60,000 h

Legal advice

• When used to replace a T8 fluorescent lamp, the total energy efficiency and light distribution depend on the design of the lighting system.

Safety advice

• Operation in outdoor applications in suitable damp-proof luminaires is possible according to the data sheet and installation instructions.
• The operating temperature range of the LED tube is restricted. In case of doubt regarding the suitability of the application, please measure the Tc temperature on the product prior to installation.
• For operation of LED TUBE T8 UN with a conventional control gear, the existing starter must be exchanged for the included LED starter in the LED tube packaging.
• All electrical connections must be made by a qualified person.
• Not suitable for emergency lighting.
