Ledvance LED linear luminaire system TruSys WIDE 53 W 3000 K SI DALI - 4058075102460
LEDVANCE
Ledvance LED linear luminaire system TruSys WIDE 53 W 3000 K SI DALI - 4058075102460
Product number:
4058075102460
Immediately available
€183.39
(6% saved)
€309.85
Content:
1 Stück
Prices incl. VAT plus shipping costs net €260.38
Product information "Ledvance LED linear luminaire system TruSys WIDE 53 W 3000 K SI DALI - 4058075102460"
Luminaire inserts with broad lighting radiation. Product properties: radiation angle: 105 °. Light output: up to 135 lm/w. Fixed electricity tapes for the electrical connection. High quality aluminum housing. Protection class: IP20. Follow the uniform design language of Ledvance (Scale Design). Product advantages: Innovative optical design with drawn stainless stainless technology over the entire light length. Inner luminaires secure the lamp against falling out during assembly. Simple electrical and mechanical connection with the supporting rail by clicking on. Homogeneous light distribution. Clean look, since assembly brackets are not visible after assembly. Plug-and-play system enables easy installation. High quality design. Light straps with up to 81 (on-off) / 99 (dali) light and a total length of 124 m (on-off) / 151 m (dali) possible. Energy savings up to 65 % compared to lights with 2 x 80 W-T5 lamps. Version available with Dali-EVG. Areas of application: Direct replacement for lights with compact fluorescent lamps. Industrial halls, high -bay warehouse, workshops, hardware stores. Discounter, supermarkets. Technical equipment: support rail with a fixed 5- (on-off) /7-pin (dali) cable strand
Downloads & Documents
Login
Electrical data
| operating frequency: | 0/50/60 Hz |
|---|---|
| operating voltage: | 220-240 V |
| rated voltage: | 220-240 V |
| lifetime: | 75000 h |
| system power: | 53 |
| switching cycles: | 100000 |
Casing
| form type: | linear |
|---|---|
| protection type: | IP20 |
| material: | aluminum |
| impact resist: | IK07 |
| protection class: | I |
| environment temperature from: | -20 °C |
| environment temperature to: | 45 °C |
Photometric data
| radiation angle: | 105 ° |
|---|---|
| dimmable: | yes |
| color: | silver |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >80 |
| lamp efficiency: | 125 lm/W |
| interface: | DALI |
| start time: | 0,5 s |
| lum flux: | 6600 lm |
Logistic data
| item category: | LED lighting strip |
|---|---|
| country of origin: | Germany |
Dimensions & packaging
| EAN | 4058075102460 |
|---|---|
| Length | 1534 mm |
| Width | 71 mm |
| Height | 53 mm |
| Weight | 1800 g |
