Ledvance LED tube LED TUBE T8 EM S 1500 mm 17.7W 840 – 4099854037658 – replacement for 58 W - 4099854037658
Shipping in 14 day(s)
Prices incl. VAT plus shipping costs net €12.90
Product information "Ledvance LED tube LED TUBE T8 EM S 1500 mm 17.7W 840 – 4099854037658 – replacement for 58 W - 4099854037658"
Powerful LED tubes for electromagnetic ballasts (KVG/VVG), splinter protection. Claimed equivalent conventional lamp power: 58 W.
Product properties
- LED replacement for conventional fluorescent lamps with G13 base in KVG or mains voltage
- Flicker -arm according to EU 2019/2020 (SVM ≤0.4 / PSTLM ≤ 1)
- Glass lamp tube with splinter protection for applications e.g. in the food industry
- VDE certified according to IEC62776
- Individual and tandem operation on conventional ballast (0.6 m version)
- Lifespan: up to 75,000 h
- Protection class: IP20
Product advantages
- no passages thanks to glass tube
- Splitter protection thanks to special PET coating
- Support in implementing the HACCP concepts from production to goods presentation
- Very high switching resistance
- High luminous flux for demanding lighting tasks
- Simple, faster and safe lamp exchange without rewiring
- Energy saving of up to 68 % (compared to T8 fluorescent lamp at the KVG)
- Full brightness without warm -up phase, therefore ideal in combination with sensors
- Also suitable for operation at low temperatures
Areas of application
- general lighting in ambient temperatures of -20 ...+50 ° C
- Lighting in industrial production
- Traffic zones and corridors
- Supermarkets and department stores
- Industry
Technical equipment
- Suitable for operation with low -loss and conventional ballast
ECG compatibility
Electronic transformers were all first developed for conventional halogen, fluorescent or compact fluorescent lamps and not for lamps with integrated electronic like LED lamps. Therefore, LEDVANCE is providing a list of electronic control gears (ECG) that have been tested and proven to be compatible with our range of LED lamps
Downloads & Documents
Electrical data
energy efficiency index: | C |
---|---|
rated voltage: | 220-240 V |
lifetime: | 75000 h |
switching cycles: | 200000 |
Casing
protection type: | IP20 |
---|---|
material: | glass |
environment temperature from: | -20 °C |
environment temperature to: | 50 °C |
Photometric data
dimmable: | no |
---|---|
color code: | 840 |
color: | white |
color temperature [Kelvin]: | 4000 |
color rendering index [CRI]: | >80 |
sensor type: | no |
socket: | G13 |
lum flux: | 3100 lm |
Dimensions & packaging
EAN | 4099854037658 |
---|---|
Length | 1513 mm |
Width | 267 mm |
Height | 267 mm |
Weight | 242 g |
