Trilux twenty3 LED recessed ceiling luminaire 2330 G3 M84 PW19 36/29/ML-8MC ET - 7798340

Name: Trilux twenty3 LED recessed ceiling luminaire 2330 G3 M84 PW19 36/29/ML-8MC ET - 7798340
Brand: TRILUX twenty3
SKU: 30141698
Price: 59.08 EUR
Availability: InStock

TRILUX twenty3

Trilux twenty3 LED recessed ceiling luminaire 2330 G3 M84 PW19 36/29/ML-8MC ET - 7798340

Product number: 7798340

Shipping in 14 day(s)

Accessories

€59.08

Content: 1 Stück

Prices incl. VAT plus shipping costs net €49.65

Accessories

Product information "Trilux twenty3 LED recessed ceiling luminaire 2330 G3 M84 PW19 36/29/ML-8MC ET - 7798340"

Luminaire type
Square LED recessed ceiling luminaire with prismatic PMMA cover. Version M84 (625 mm x 625 mm). Version with 2-stage
adjustable luminous flux and 2-stage adjustable light color.

Application areas
Offices, corridors, foyers, conference rooms, sales areas, waiting areas.

Mounting types
For system ceilings with visible mounting rails. Version M84, system dimension 625 x 625 mm.

Optical system
PMMA cover with microprismatics. With deep-wide distribution of luminous intensity. Glare rating according to UGR classification (EN 12464-1) <19. Screen-compatible according to EN 12464-1 due to limited luminance L ≤ 3000 cd/m 2 for beam angles above 65° all-round. Harmonious lighting effect due to uniformly illuminated light emission.
LED system Luminaire with adjustable rated luminous flux 2900 lm - 3600 lm. Rated power depending on the adjusted luminous flux 24.00 W -31.00 W. Power factor λ > 0.95, luminaire luminous efficacy 120 lm/W. Light color warm white or neutral white, most similar color temperature (CCT) variable (3000 K - 4000 K), general color rendering index (CRI) R a > 80. Color location tolerance (initial MacAdam) ≤ 5 SDCM, Average rated life L65(t q 25 °C) = 50,000 h.

Luminaire body
Luminaire body made of aluminum. Surface coated white (RAL 9016). Dimensions (L x W): 620 mm x 620 mm, luminaire height 69 mm. Weight: 2.2 kg.

Electrical version
With electronic control gear, switchable. The control gear is replaceable in accordance with the ecodesign requirements (VO (EU) 2019/2020).

The product meets the essential requirements of the applicable EU directives and product safety law and bears the CE marking. In addition, the luminaire is ENEC-certified by an independent testing body.

Downloads & Documents

Datenblatt_2330_G3_7798340_DE
Montageanleitung_manual_2330_G3__DE_EN

Electrical data

operating frequency:	50/60 Hz
through wiring:	no
rated voltage:	220-240 V
terminal type:	plug-in terminal
lifetime:	50000 h

Casing

ballproof:	no
fire protection:	no
form type:	square
protection type:	IP20/40
material:	aluminum
impact resist:	IK02
protection class:	I
environment temperature to:	25 °C

Photometric data

multi-color:	yes
multi-lumen:	yes
radiation angle:	65 °
sensor:	no
dimmable:	no
color:	white
color temperature [Kelvin]:	3000/4000
color rendering index [CRI]:	>80
lamp type:	LED
lamp efficiency:	116/120 lm/W
inclusive lamp:	yes
sensor type:	no
solar panel:	no
