Tridonic LED-Driver LCI 105W 200-850mA pD NF h28 PRE4 (INDUSTRY) - 28004036
Tridonic GmbH & Co KG
Tridonic LED-Driver LCI 105W 200-850mA pD NF h28 PRE4 (INDUSTRY) - 28004036
Product number:
28004036
Shipping in 14 day(s)
€60.69
Prices incl. VAT plus shipping costs net €51.00
Product information "Tridonic LED-Driver LCI 105W 200-850mA pD NF h28 PRE4 (INDUSTRY) - 28004036"
Product description
- Constant current built-in Driver for LED, particularly suitable for industrial applications in tough environments with elevated ambient temperatures such as warehouses or factories
- Certified D4i product
- Dimming range 1 to 100 %
- For luminaires of protection class I and protection class II
- Output current adjustable between 200 – 850 mA
- Max. output power 105 W
- Suitable for mains voltage peaks (burst/surge) up to 4 kV
- Expanded temperature range of -40 ... +80 °C
- Nominal lifetime up to 100,000 h (at ta 60 °C)
- 8 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)
Housing properties
- White slim metal casing
- Type of protection IP20
Interfaces
- Near field communication (NFC)
- one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION)
- Terminal blocks: 0° push terminals
Functions
- Adjustable output current in 1-mA-steps (NFC, DALI)
- Fulfills DALI-2 parts: 250 (Integrated bus power supply), 251 (Luminaire data), 252 (Energy reporting) and 253 (Diagnostics & Maintenance)
- Constant light output function (CLO)
- Intelligent Temperature Guard (overtemperature protection)
- Intelligent Voltage Guard (overvoltage and undervoltage monitoring)
- Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
- Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
- Flexible configuration via companionSUITE (NFC, DALI)
- Application-oriented operating window for maximum compatibility
- Extended vibration damping
- Increased safety through robust design and advanced testing under extreme test conditions
- High reliability through the selection of exclusive components
Typical applications
- For linear/area lighting in industry applications
EAN/UPC: 9006210777290
Country of Origin: AT
Customs tariff No.: 85044095
Downloads & Documents
Electrical data
| output current: | 200, 300, 350, 550, 750, 850 |
|---|---|
| operating mode: | constant current |
