Tridonic LED-Driver LC 25W 50–350mA 230V bDW NFC h16 PRE4 - 28004617
Tridonic GmbH & Co KG
Tridonic LED-Driver LC 25W 50–350mA 230V bDW NFC h16 PRE4 - 28004617
Product number:
28004617
Shipping in 7 day(s)
€84.54
Prices incl. VAT plus shipping costs net €71.04
Product information "Tridonic LED-Driver LC 25W 50–350mA 230V bDW NFC h16 PRE4 - 28004617"
Product description
- Can be integrated in Casambi systems (Casambi Ready)
- NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
- Dimmable built-in constant current LED driver
- Dimming range 1 to 100 %
- For luminaires of protection class I and protection class II
- Output current adjustable between 50 – 350 mA
- Max. output power 25 W
- Up to 91.1 % efficiency
- Power input on stand-by < 0.14 W
- Nominal lifetime up to 100,000 h
- 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)
Housing properties
- Low profile metal casing with white cover
- Only 16 mm housing height
- Type of protection IP20
Interfaces
- basicDIM Wireless
- Near field communication (NFC)
- switchDIM
- Terminal blocks: 0° push terminals
Functions
- Adjustable output current in 1-mA-steps (NFC)
- lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance)
- Constant light output function (eCLO)
- Power-up fading at AC
- Switch off the driver with fade2zero
- Protective features (overtemperature, short-circuit, overload, no-load)
- Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
- Flexible configuration via companionSUITE
- Support NFC multiple programming (full carton box)
- Application-oriented operating window for maximum compatibility
- Best energy savings due to low stand-by losses and high efficiency
- Reliability proven by lifetime up to 100,000 h and 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)
Typical applications
- For linear/area lighting in office applications
EAN/UPC: 9006210801315
Country of Origin: AT
Customs tariff No.: 85044083
Downloads & Documents
Electrical data
| output current: | 50, 100, 150, 200, 250, 300, 350 |
|---|---|
| operating mode: | constant current |
