Ledvance LED high bay luminaire hall luminaire HIGH BAY COMPACT 83W 840 110DEG IP65 – 4058075708174
LEDVANCE
Ledvance LED high bay luminaire hall luminaire HIGH BAY COMPACT 83W 840 110DEG IP65 – 4058075708174
Product number:
4058075708174
Shipping in 3 day(s)
€140.55
Content:
1 Stück
Prices incl. VAT plus shipping costs net €118.11
Product information "Ledvance LED high bay luminaire hall luminaire HIGH BAY COMPACT 83W 840 110DEG IP65 – 4058075708174"
Hall luminaires up to 120 lm/w. Product properties: ambient temperature: -20 ... 45 ° C. Black aluminum housing, coverage made of safety glass. Opal cover. Protection class: IP65. Lifespan (L70): up to 50,000 h. High luminaire output: up to 120 lm/w. Product advantages: modern, exclusive design. Up to 60 % energy savings compared to conventional indoor mirror luminaires. 3 year guarantee. Weight and size optimization through compact design. Areas of application: replacement for indoor mirror luminaires with mercury steam or halogen metal steam lamps. Warehouses. Logistics halls. Industry. High ceilings (e.g. in shopping centers, airports, business buildings, lobbies). Technical equipment available: bracket available. Reflector available
Downloads & Documents
Electrical data
| operating frequency: | 50/60 Hz |
|---|---|
| through wiring: | no |
| rated voltage: | 220-240 V |
| switching cycles: | 100000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| protection type: | IP65 |
| material: | aluminum |
| mounting: | suspended, surface mounting |
| impact resist: | IK06 |
| protection class: | I |
| environment temperature from: | -20 °C |
| environment temperature to: | 45 °C |
Photometric data
| radiation angle: | 110 ° |
|---|---|
| dimmable: | no |
| color code: | 840 |
| color: | black |
| color temperature [Kelvin]: | 4000 |
| color rendering index [CRI]: | >80 |
| lamp efficiency: | 120 lm/W |
| inclusive lamp: | yes |
| solar panel: | no |
| lum flux: | 10000 lm |
Dimensions & packaging
| EAN | 4058075708174 |
|---|---|
| Length | 180 mm |
| Width | 180 mm |
| Height | 50 mm |
| Weight | 800 g |
