Lunatone motion detector Dali CS Movement 12m/Light/Temp, black RAL9005 - 86458621-B-AP
Lunatone
Lunatone motion detector Dali CS Movement 12m/Light/Temp, black RAL9005 - 86458621-B-AP
Product number:
86458621-B-AP
Shipping in 5 day(s)
€112.34
Content:
1 Stück
Prices incl. VAT plus shipping costs net €94.40
Product information "Lunatone motion detector Dali CS Movement 12m/Light/Temp, black RAL9005 - 86458621-B-AP"
A compact DALI motion detector with integrated light and temperature sensor. The module can be used as a control unit for a DALI system or as a measurement tool in combination with central control unit. The module is suitable for various applications such as offices, class rooms, corridors or halls. Following settings can be configured: target address, DALI command for on/off, activate /deactivate each sensor, constant light control and hold time. Multiple sensors within one group synchronise automatically. The DALI CS can be easily installed in flush-mounted boxes or directly on cavity walls. Different versions for surface mounting and suspended ceilings are available.
Downloads & Documents
Electrical data
| conformity: | CE |
|---|
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | round |
| max housing temperature (tc-max): | 70 °C |
| protection type: | IP20 |
| material: | plastic |
| mounting: | surface-mounted |
| protection class: | II |
| environment temperature from: | -20 °C |
| environment temperature to: | 70 °C |
Photometric data
| sensor: | yes |
|---|---|
| response brightness to: | 2500 Lux |
| response brightness from: | 0 Lux |
| color: | black |
| detection range: | 12 m |
| interface: | DALI |
| sensor type: | passive infrared |
Logistic data
| country of origin: | Bulgaria |
|---|
Dimensions & packaging
| EAN | 9010342014185 |
|---|---|
| Length | 98 mm |
| Width | 98 mm |
| Height | 18 mm |
| Weight | 121 g |
