Ledvance LED tube LED TUBE T5 HF P 1449 mm 18W 830 – 4099854029172 – replacement for 35 W - 4099854029172

LEDVANCE

Ledvance LED tube LED TUBE T5 HF P 1449 mm 18W 830 – 4099854029172 – replacement for 35 W - 4099854029172

Product number: 4099854029172

Shipping in 3 day(s)

e
a g
Datasheet

€17.16


Content: 1 Stück

Prices incl. VAT plus shipping costs net €14.42

Product information "Ledvance LED tube LED TUBE T5 HF P 1449 mm 18W 830 – 4099854029172 – replacement for 35 W - 4099854029172"

LED tubes for electronic ballasts. Product properties: Retrofit replacement of existing T5 lamps on HF ballasts. Glass lamp tube with splinter protection for applications e.g. in the food industry. High color consistency: ≤ 5 sdcm (threshold value unit). Lifespan: up to 50,000 h. Flicker arm according to EU 2019/2020. Protection class: IP20. Compatible with many commercially available electronic ballasts (see also Compatibility list ). Product advantages: No passages thanks to glass technology. Simple, faster and safe lamp exchange without rewiring. High luminous flux for demanding lighting tasks. Areas of application: offices, public institutions. Supermarkets and department stores. Industry. General lighting in ambient temperatures of -20 ...+45 ° C.



ECG compatibility

Electronic transformers were all first developed for conventional halogen, fluorescent or compact fluorescent lamps and not for lamps with integrated electronic like LED lamps. Therefore, LEDVANCE is providing a list of electronic control gears (ECG) that have been tested and proven to be compatible with our range of LED lamps

Follow this link to the ECG compatibility list

Electrical data
operating frequency: 20-75 Hz
energy efficiency index: E
lifetime: 50000 h
system power: 18
switching cycles: 200000
Casing
fire protection: no
form type: linear
protection type: IP20
material: glass
Photometric data
dimmable: no
color code: 830
color: white
color temperature [Kelvin]: 3000
color rendering index [CRI]: >80
lamp type: LED
socket: G5
lum flux: 2550 lm
Logistic data
country of origin: China
Dimensions & packaging
EAN 4099854029172
Length 1449 mm
Width 17 mm
Height 17 mm
Weight 192 g
