Ledvance LED spotlight SPOT AIR FIX 6W 930 PS DIM IP65 BK - 4058075799967
LEDVANCE
Ledvance LED spotlight SPOT AIR FIX 6W 930 PS DIM IP65 BK - 4058075799967
Product number:
4058075799967
Immediately available
€25.70
Content:
1 Stück
Prices incl. VAT plus shipping costs net €21.60
Product information "Ledvance LED spotlight SPOT AIR FIX 6W 930 PS DIM IP65 BK - 4058075799967"
Recessed spotlights for low-energy and tight false ceilings, determined. Product properties: Color rendering index R a : 90. Protection class: IP65 (space side). Ray angle: 36 °. Aluminum die -cast housing. Springs with a soft silicone coating. Dimmable (at many standard dimmers, see also www.ledvance.de/dim ). Wiring through. Product advantages: Airtight construction for reduced air clever and reduced energy loss. Coverable with many types of thermal insulation materials. Flat construction enables installation into low ceiling cavities. Powerselect: Adjustment of the brightness via DIP switches on the driver. Easy replacement of the external driver thanks to the plug with bayonet closure. Easy installation and electrical connection thanks to tool -free connection clamps. Scale design - great appearance, high -quality materials and small size fit in any environment. 5 years of guarantee. Areas of application: Direct replacement for recessed spotlights with halogen lamps. Ceilings in low -energy houses. General lighting. Hotel room and corridore. Bars, restaurants. Accent lighting. Living rooms. Technical equipment: External ballast with DIP switches to adjust the power during installation.
Downloads & Documents
Electrical data
| operating frequency: | 50-60 Hz |
|---|---|
| rated voltage: | 220-240 V |
| conformity: | CB, CE, EAC, ENEC, TÜV Süd, UKCA |
| lifetime: | 50000 h |
| switching cycles: | 100000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | round |
| protection type: | IP20/65 |
| material: | aluminum |
| mounting: | ceiling mounting, Installation |
| impact resist: | IK03 |
| protection class: | II |
| environment temperature from: | -20 °C |
| environment temperature to: | 40 °C |
Photometric data
| radiation angle: | 36 ° |
|---|---|
| sensor: | no |
| dimmable: | yes |
| color code: | 830 |
| color: | black |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >90 |
| lamp type: | LED |
| lamp efficiency: | 85 lm/W |
| inclusive lamp: | yes |
| interface: | Phase cut |
| sensor type: | no |
| solar panel: | no |
| lum flux: | 510 lm |
Logistic data
| item category: | LED ceiling luminaires |
|---|
Dimensions & packaging
| EAN | 4058075799967 |
|---|---|
| Length | 100 mm |
| Width | 105 mm |
| Height | 85 mm |
| Weight | 385 g |
