Ledvance LED high bay luminaire HIGH BAY SENSOR GEN 4 147W 840 70DEG IP65 – 4058075603271
LEDVANCE
Ledvance LED high bay luminaire HIGH BAY SENSOR GEN 4 147W 840 70DEG IP65 – 4058075603271
Product number:
4058075603271
Shipping in 3 day(s)
€266.62
Content:
1 Stück
Prices incl. VAT plus shipping costs net €224.05
Product information "Ledvance LED high bay luminaire HIGH BAY SENSOR GEN 4 147W 840 70DEG IP65 – 4058075603271"
Hall luminaires up to 150 lm/w with high frequency sensor. Product properties: high frequency sensor for dayluminaire and movement recording. Different luminaire flows and angles for assembly heights from ~ 6 m to 10 m in 4000 K. Product advantages: multiple setting options of sensor area, dayluminaire detection and retention time. High luminaire output. Up to 64 % energy savings compared to conventional indoor mirror luminaires. 5 years of guarantee. Suitable for use in dusty and moist environments thanks to the high type of protection. Areas of application: replacement for indoor mirror luminaires with mercury steam or halogen metal steam lamps. Warehouses. Logistics halls. Industry. High ceilings (e.g. in shopping centers, airports, business buildings, lobbies). Technical equipment: sensor, assembly ring and assembly bracket. Reflectors, refractors and remote control available as separate accessories available
Downloads & Documents
Electrical data
| operating frequency: | 50/60 Hz |
|---|---|
| through wiring: | no |
| rated voltage: | 220-240 V |
| lifetime: | 100000 h |
| system power: | 147 |
| switching cycles: | 200000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| protection type: | IP65 |
| material: | aluminum |
| mounting: | suspended, surface mounting |
| impact resist: | IK08 |
| protection class: | I |
| environment temperature from: | -20 °C |
| environment temperature to: | 50 °C |
Photometric data
| radiation angle: | 70 ° |
|---|---|
| dimmable: | no |
| color code: | 840 |
| color: | black |
| color temperature [Kelvin]: | 4000 |
| color rendering index [CRI]: | >80 |
| lamp efficiency: | 150 lm/W |
| inclusive lamp: | yes |
| solar panel: | no |
| lum flux: | 22000 lm |
Dimensions & packaging
| EAN | 4058075603271 |
|---|---|
| Length | 321 mm |
| Width | 321 mm |
| Height | 188 mm |
| Weight | 2690 g |
