M. Züblin AG

Züblin Motion detector Swiss Garde 3100 IR 14 m black

Product number: 26470
M. Züblin AG

Züblin Motion detector Swiss Garde 3100 IR 14 m black

Product number: 26470

Immediately available

The Züblin motion detector Swiss Garde 3100 ir 14 m is a compact surface mounted / flush mounted infrared motion detector. It is suitable for wall and ceiling mounting in all areas with little interference sources (indoors and outdoors). Thanks to its equipment with the IP55 protection, it is ... Read more

€58.23

Product information "Züblin Motion detector Swiss Garde 3100 IR 14 m black"

The Züblin motion detector Swiss Garde 3100 ir 14 m is a compact surface mounted / flush mounted infrared motion detector. It is suitable for wall and ceiling mounting in all areas with little interference sources (indoors and outdoors).

Thanks to its equipment with the IP55 protection, it is reliably protected against dust as well as water and is thus particularly ideal for outdoor use. The Züblin AP/Up Motion detector Swiss Garde 3100 ir 14 m has a 360 ° creep protection and a detection range of 200 °. The motion capture includes a radius of 14m. The motion detector can be used at an assembly height of 2 to 8 meters. The rotary and tilting sensor head ensures an optimal setting.

In addition to its PIR sensor (PIR=Infrared), the motion detector Swiss Garde 3100 IR 14 m also has daylight-illumination control, which can be switched on and off. You can program the AP/Up motion detector Swiss Garde 3100 IR 14 optionally via RC Radio remote control (RC = Radio controlled) or PRT IR-handheld transmitter. Both of these items can be found and ordered in the cross-selling area at the bottom oft he page. Züblin offers 5 years of manufacturer's warranty for all products.

Technical Data

Logistic Data

EAN (pcs): 3505100264705

Customs tariff number: 85365080

Country of Origin: China

Electrical Data

Rated Voltage: 230V

Rated frequency: 50/60Hz

Switching capacity ohmic: 2300W

Switching capacity inductive (cos φ=0.5): 1150VA

Technical lighting data

Response brightness: 5-2000lx

Detection angle: 200°

Detection Range: ca. 12 m frontal und ca. 6 m seitlich bei 3 m Höhe, Ø 5 m Unterkriechschutzm

Time setting: 10 s - 20 m

Dimmable: no

Housing Color: black

Dimensions

Width [mm]: 63mm

Height [mm]: 63mm

Length [mm]: 62mm

Mounting method: surface mounting

Housing

IP protection class: IP55

Ambient temperature (ta): -20...+55°C

Protection class: II

Item number: 26470

Den Züblin P- IR-Handsender für die Swissgarde Bewegungs/Präsenzmelder können Sie hier mitbestellen:

Den Züblin P- IR-Handsender für die Swissgarde Bewegungs/Präsenzmelder können Sie hier mitbestellen:

Art.-Nr.: 25320
The PIR hand transmitter is suitable for all programmable Swiss-Garde Presence - And mot…

€11.45 net €9.62

Immediately available
