Product information "Theben Installation PIR Motion Detector thePassa P360-101 UP WH White - 7612748006539"
PIR presence detector for ceiling mounting
The passive infrared passive motion detector thePassa P360 Slave UP by Theben is suitable for ceiling mounting in a flush-mounted box. Ceiling mounting is also possible with a surface-mounted frame. Thanks to its square detection area, it is perfect for corridors and storage aisles.
Detection area with 2 on/off switchable zones
The presence detector has a detection area with two individually selectable and disconnectable detection zones, each measuring 15 x 5 m (total 30 x 5 m). A test mode is used to check the function and the detection range. Due to the factory presetting, the motion detector is ready for immediate use.
An extension of the detection are can be achieved by a Master/Slave or Master/Master circuit, whereby a maximum of 10 detectors can be connected in parallel. Optionally, the presence detector can be controlled with the theSenda S user remote control or the SendoPro management remote control.
Downloads & Documents
Login
Electrical data
| rated voltage: | 110-230 V |
|---|
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| protection type: | IP54 |
| mounting: | flush mounting |
| environment temperature from: | -15 °C |
| environment temperature to: | 50 °C |
Photometric data
| sensor: | yes |
|---|---|
| color: | white |
| interface: | On-Off |
| sensor type: | passive infrared |
| solar panel: | no |
Logistic data
| item category: | sensors |
|---|
Dimensions & packaging
| EAN | 7612748006539 |
|---|---|
| Height | 83 mm |
| Weight | 210 g |
